3514-2 Shear

Draco
(Code: Draco-61070-1GB)
Up to 2.0mm, or 4 x 0.9mm steel, or 6 x 0.75mm light metal

Ideal for cutting spiral ducts, standing seams and cross welts.
£594.00
2000
  1. Up to 2.0mm, or 4 x 0.9mm steel, or 6 x 0.75mm light metal

    • Cold cutting without flying sparks!
    • Ideal for cutting spiral ducts, standing seams, cross welts made of steel, aluminum, lead, copper, zinc or stainless steel.
    • Also suitable for roller shutters, mesh and wire etc.

    Other Applications
    • Shutter construction
    • Awning construction
    • House construction
    • Cages
    • Steel (400N/mm²) capacity: 2mm
    • Stainless steel (600N/mm²) capacity: 1.5mm
    • Stainless steel (800N/mm²) capacity: 1.3mm
    • Aluminium (250N/mm²) capacity: 3mm
    • Lead capacity: 4mm
    • Spiral duct (400N/mm²): 4 x 0.9mm
    • Duct & Pittsburgh Seam (400N/mm²): 4 x 0.9mm
    • Double lock seam (250N/mm²): 6 x 0.75mm
    • Tightest radius: 200mm
    • Working speed: 5-7m per min
    • Strokes: 2400 per min
    • Motor capacity: 500 watts
    • Voltage: 115V
    • Weight: 2kg
